Product Summary
The IS61LV64168T is a high-speed, CMOS static RAM. It is organized as 65,536 words by 16 bits, fabricated with ICSI advanced CMOS technology. When CE is high, the IS61LV64168T assumes a standby mode at which the power dissipation can be reduced down with CMOS input levels.
Parametrics
IS61LV64168T absolute maximum ratings: (1)TSTG Storage Temperature: –65 to +150 ℃; (2)PD Power Dissipation: 1.5 W; (3)IOUT Output Current (per I/O): 20 mA; (4)VIN, VOUT Voltage Relative to GND for I/O Pins: –0.5 to VCCQ + 0.5 V.
Features
IS61LV64168T features: (1)High speed access time: 8, 10 12, and 15ns; (2)CMOS low power operation; (3)TTL compatible interface levels; (4)Single 3.3V power supply; (5)Fully static operation: no clock or refresh required; (6)Three state outputs; (7)Data control for upper and lower bytes; (8)Industrial temperature available.
Diagrams
 |
