PEEL18CV8PI25L

DIP20, CMOS Programmable, Electrically Erasable Logic Device, -0.5 to + 6.0 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1.50

PartNumber:: PEEL18CV8PI25L

Brand:: Integrated Circuit Technology Corp - ICT | Pack: DIP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Susan's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-04-17

From Other Seller

Part Number:PEEL18CV8PI25L
US $1.00 - 1.50
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PEEL18CV8PI25L is a Programmable Electrically Erasable Logic (PEEL) device providing an attractive alternative to ordinary PLDs. The PEEL18CV8PI25L offers the performance, flexibility, ease of design and production practicality needed by logic designers today. The PEEL18CV8PI25L is available in 20-pin DIP, PLCC, SOIC and TSSOP packages with speeds ranging from 5ns to 25ns with power consumption as low as 37mA. EE-eprogrammability of the PEEL18CV8PI25L provides the convenience of instant reprogramming for development and reusable production inventory minimizing the impact of programming changes or errors. EE-Reprogrammability also improves factory testability, thus assuring the highest quality possible.

Parametrics

PEEL18CV8PI25L absolute maximum ratings: (1)VCC Supply Voltage Relative to Ground: -0.5 to + 6.0 V; (2)VI, VO Voltage Applied to Any Pin2 Relative to Ground1: -0.5 to VCC + 0.6 V; (3)IO Output Current Per Pin (IOL, IOH): ±25 mA; (4)TST Storage Temperature: -65 to +150 ℃; (5)TLT Lead Temperature Soldering 10 Seconds: +300 ℃.

Features

PEEL18CV8PI25L features: (1)Multiple Speed Power, Temperature Options; (2)CMOS Electrically Erasable Technology; (3)Development / Programmer Support; (4)Architectural Flexibility; (5)Enhanced architecture fits in more logic; (6)74 product terms x 36 input AND array; (7)10 inputs and 8 I/O pins; (8)12 possible macrocell configurations.
