AT49BV160C70TU

2.7-volt, 16-megabit Flash memory, 48-lead TSOP, 2.65V to 3.6V, 70 ns, 12μs, AT49BV160C70TU

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.50~1.70 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.50~1.70

PartNumber:: AT49BV160C70TU

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Susan's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-04-17

From Other Seller

Part Number:AT49BV160C70TU
US $1.50 - 1.70
IRF3205

US $0.80 - 2.50 / Piece
(0) Remove
SIL9185ACTU

US $2.30 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT49BV160C70TU is a 2.7-volt 16-megabit Flash memory organized as 1,048,576 words of 16 bits each. The memory is divided into 39 sectors for erase operations. The AT49BV160C70TU is offered in a 48-lead TSOP and a 46-ball CBGA package. The device has CE and OE control signals to avoid any bus contention. This device can be read or reprogrammed using a single power supply, making it ideally suited for in-system programming.

Parametrics

AT49BV160C70TU absolute maximum ratings: (1)Temperature under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5)Voltage on VPP with Respect to Ground: -0.6V to +13.0V.

Features

AT49BV160C70TU features: (1)Single Voltage Read/Write Operation: 2.65V to 3.6V; (2)Access Time: 70 ns; (3)Sector Erase Architecture: Thirty-one 32K Word (64K Bytes) Sectors with Individual Write Lockout; Eight 4K Word (8K Bytes) Sectors with Individual Write Lockout; (4)Fast Word Program Time: 12μs; (5)Fast Sector Erase Time: 300 ms; (6)Suspend/Resume Feature for Erase and Program; (7)Supports Reading and Programming from Any Sector by Suspending Erase of a Different Sector; (8)Supports Reading Any Word by Suspending Programming of Any Other Word; (9)Low-power Operation: 12 mA Active; 13μA Standby; (10)VPP Pin for Write Protection; (11)WP Pin for Sector Protection; (12)RESET Input for Device Initialization; (13)Flexible Sector Protection; (14)TSOP and CBGA Package Options; (15)Top or Bottom Boot Block Configuration Available; (16)128-bit Protection Register; (17)Minimum 100,000 Erase Cycles; (18)Common Flash Interface (CFI).
