Product Summary
The 8406801VA is a high performance CMOS Clock Generator-driver which is designed to service the requirements of both CMOS and NMOS microprocessors such as the 80C86, 80C88, 8086 and the 8088. The 8406801VA contains a crystal controlled oscillator, a divide-by-three counter and complete Ready synchronization and reset logic. Static CMOS circuit design permits operation with an external frequency source from DC to 25MHz. Crystal controlled operation to 25MHz is guaranteed with the use of a parallel, fundamental mode crystal and two small load capacitors.
Parametrics
8406801VA absolute maximum ratings: (1)Supply Voltage: +8.0V; (2)Input, Output or I/O Voltage: GND -0.5V to VCC +0.5V; (3)ESD Classification: Class 1; (4)Storage Temperature Range: -65℃ to +150℃; (5)Max Junction Temperature: +175℃; (6)Lead Temperature (Soldering 10s): +300℃ (PLCC - Lead Tips Only).
Features
8406801VA features: (1)Generates the System Clock For CMOS or NMOS Microprocessors; (2)Up to 25MHz Operation; (3)Uses a Parallel Mode Crystal Circuit or External Frequency Source; (4)Provides Ready Synchronization; (5)Generates System Reset Output From Schmitt Trigger Input; (6)TTL Compatible Inputs/Outputs; (7)Very Low Power Consumption; (8)Single 5V Power Supply; (9)Operating Temperature Ranges: C82C84A: 0℃ to +70℃; I82C84A: -40℃ to +85℃; M82C84A: -55℃ to +125℃.
Diagrams
 |
