S29AL016M90FAI020

16 Mbit, 3.0 Volt-only Flash memory, 200 mA, FBGA, S29AL016M90FAI020

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.50~3.00

PartNumber:: S29AL016M90FAI020

Brand:: SPANSION - spansion | Pack: DIP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Susan's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-14

From Other Seller

Part Number:S29AL016M90FAI020
US $2.50 - 3.00
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
SLA4060

US $0.80 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The S29AL016M90FAI020 is a 16 Mbit, 3.0 Volt-only Flash memory organized as 2,097,152 bytes or 1,048,576 words. The device is offered in a 48-ball Fine-pitch BGA, 64-ball Fortified BGA, and 48-pin TSOP packages. The word-wide data (x16) appears on DQ15–DQ0; the byte-wide (x8) data appears on DQ7–DQ0. The S29AL016M90FAI020 requires only a single 3.0 volt power supply for both read and write functions, designed to be programmed in-system with the standard system 3.0 volt VCC supply. The S29AL016M90FAI020 can also be programmed in standard EPROM programmers.

Parametrics

S29AL016M90FAI020 absolute maximum ratings: (1)Storage Temperature, Plastic Packages:–65 to +150℃; (2)Ambient Temperature with Power Applied:.–65 to +125℃; (3)Voltage with Respect to Ground, VCC:–0.5 V to +4.0 V; (4)A9, OE#, and RESET# : –0.5 V to +12.5 V; All other pins: –0.5 V to VCC+0.5 V; (5)Output Short Circuit Current: 200 mA.

Features

S29AL016M90FAI020 features: (1)program Suspend & Resume: read other sectors before programming operation is completed; (2)Erase Suspend & Resume: read/program other sectors before an erase operation is completed; (3)Data# polling & toggle bits provide status; (4)Unlock Bypass Program command reduces overall multiple-word programming time ; (5)CFI (Common Flash Interface) compliant: allows host system to identify and accommodate multiple flash devices.
