Product Summary
The MC54F13J is a schmitt triggers dual 4-input nand/hex inverter. The MC54F13J contains logic gates/inverters which accept standard TTL input signals and provide standard TTL output levels. The MC54F13J is capable of transforming slowly changing input signals into sharply defined, jitter-free output signals. Additionally, they have greater noise margin than conventional inverters.
Parametrics
MC54F13J absolute maximum ratings: (1)VCC, Supply Voltage: 4.5 to 5.5 V; 5.0V typ; (2)TA, Operating Ambient Temperature Range: –55 to 125℃; 25℃ typ; (3)IOH, Output Current-High: –1.0 mA; (4)IOL, Output Current-Low: 20 mA.
Features
MC54F13J features: (1)Military/High-Rel: N; (2)Tech.: TTL; (3)Circuits Per Package: 2; (4)Hysteresis Voltage Typ. (V): 800m; (5)Input Threshold Voltage (+)(V): 2.0; (6)Input Threshold Voltage (-)(V): 0.8; (7)Maximum Input Current (A): 180u; (8)t(PLH) Maximum (S): 9.0n; (9)VOL Max.: 0.5; (10)VOH Min.: 2.5; (11)Noise Margin - Minimum (V): 500m; (12)Nom. Supp (V): 5.0; (13)Minimum Operating Temp (℃): -55; (14)Maximum Operating Temp (℃): 125; (15)Package Style: DIP; (16)Mounting Style: T; (17)# Pins: 14.
