Product Summary
The GS74116AGP10 is a high speed CMOS Static RAM organized as 262,144 words by 16 bits. Static design eliminates the need for external clocks or timing strobes. The GS74116AGP10 operates on a single 3.3 V power supply and all inputs and outputs are TTLcompatible. The GS74116AGP10 is available in a 6 x 10 mm Fine Pitch BGA package, 400 mil SOJ and 400 mil TSOP Type-II packages.
Parametrics
GS74116AGP10 absolute maximum ratings: (1)Supply Voltage VDD: –0.5 to +4.6 V; (2)Input Voltage VIN: –0.5 to VDD +0.5 (≦ 4.6 V max.) V; (3)Output Voltage VOUT: –0.5 to VDD +0.5 (≦ 4.6 V max.) V; (4)Allowable power dissipation PD: 0.7 W; (5)Storage temperature TSTG: –55 to 150 ℃.
Features
GS74116AGP10 features: (1)Fast access time: 7, 8, 10, 12 ns; (2)CMOS low power operation: 150/130/105/95 mA at minimum cycle time; (3)Single 3.3 V power supply; (4)All inputs and outputs are TTL-compatible; (5)Byte control; (6)Fully static operation; (7)Industrial Temperature Option: 0 to 85℃
Diagrams
 |
