54FCT244TDB

Buffer/Line Driver, 8-Channel, Non-Inverting, dual metal CMOS, CDIP20, 3.3V, 54FCT244TDB

Rated 5 Rating 5 | reviews | Write a review

Price:: US $9.00~10.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $9.00~10.00

PartNumber:: 54FCT244TDB

Brand:: Integrated Device Technology - IDT | Pack: DIP | D/C: 00+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Susan's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-04

From Other Seller

Part Number:54FCT244TDB
US $9.00 - 10.00
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 54FCT244TDB is a kind of octal buffer/line driver which is built using an advanced dual metal CMOS technology. The device is designed to be employed as a memory and address driver, clock driver, and bus-oriented transmitter/ receiver which provides improved board density.

Parametrics

54FCT244TDB absloute maximum ratings: (1)VTERM(Inputs and Vcc terminals only), Terminal Voltage with Respect to GND: –0.5 to +7 V; (2)VTERM(Output and I/O terminals only), Terminal Voltage with Respect to GND: –0.5 to VCC+0.5 V; (3)TSTG, Storage Temperature: –65 to +150℃; (4)IOUT, DC Output Current: –60 to +120 mA.

Features

54FCT244TDB features: (1)Std., A, and C grades; (2)Low input and output leakage .1≦μA (max.); (3)CMOS power levels; (4)True TTL input and output compatibility: VOH = 3.3V (typ.); VOL = 0.3V (typ.); (5)High Drive outputs (-15mA IOH, 64mA IOL); (6)Meets or exceeds JEDEC standard 18 specifications; (7)Military product compliant to MIL-STD-883, Class B and DESC; (8)listed (dual marked); (9)Power off disable outputs permit live insertion; (10)Available in the fol.lowing packages: Industrial: SOIC, SSOP, QSOP, TSSOP; Military: CERDIP, LCC.
